Sintonizador Radio Project Tuner Box

Project Tuner Box
Novedad

Producto Agotado y Descatalogado. Sustituido por Project Tuner Box S2

.

.

Envío gratuito

Receiver with FM tuner and remote control


PRODUCTO SUSTITUIDO POR PROJECT TUNER BOX S



Good sound from sound technology

Metal case shields the electronics from vibrational and electromagnetic interference

Bi-Phase PWM-circuit (Pulse Width Modulation)

Gold plated RCA/Phono sockets and loudspeaker terminals

Outboard power supply included



Features

Remote controllable

Small size allows easy placement

Two line-level inputs

99 Programmable presets. 8 presets with direct access via remote control

Fine tuning meter, signal strength meter and stereo/mono reception indicator

Display dimmable

Pro-Ject Audio digital amplifiers achieve 80% energy efficiency

Available in black and silver

Technical specifications Pro-Ject Receiver Box
Power output 2 x 20W/30W at 8ohms/4ohms (both channels driven)
Tuning range FM-band 87,5 - 108,5MHz (50kHz steps)
Programmable presets 99
THD tuner 0,05% / Df 75kHz and f mod 1kHz
Stereo separation 30dB / Df 75kHz and f mod 1kHz
Sensitivity 7dB/ľV mono, 17dB/ľV stereo /75 ohms
Frequency response 20Hz - 20kHz (Ä0,2dB)
Channel separation > 40dB at 20kHz
Noise floor > -100dB (A weighted)
THD amplifier < 0,05% at 10W
Gain 22dB
Line-level inputs 1 pair RCA/Phono sockets, 3-pole Å 2,5mm co-axial jack
Input impedance 20kohms
Antenna input 1 x co-axial DIN-socket (75 ohms) / US-model F-socket
Outboard power supply 20V/3A DC (peak 7A DC), suitable for your country's mains supply
Power consumption 20V/3A DC
Replacement battery remote control 1 x CR 2025 / 3V
Dimensions (W x H x D) 103 x 38 x 141mm
Weight 670g without power supply
